Land Use Plan DWG Example – How to Read & Redraw It in AutoCAD

Download a free DWG of a land use zoning map. Learn how to analyze, recreate, and master planning drawings using AutoCAD with this step-by-step guide for students and professionals.



📍 1. What This Drawing Shows?

This drawing is a schematic land use plan typically used in:

  • Urban planning projects
  • Architecture or landscape architecture studios
  • GIS & site analysis exercises



It uses colors and zones to indicate different land functions — useful for:

  • Masterplans
  • Area development plans
  • Urban renewal concepts



🎓 2. Who Should Use This?

✅ Architecture & Planning Students: Understand how to interpret abstract zoning plans
✅ Professionals: Use as a template or reference for new township/site layouts
✅ GIS or Urban Design Projects: Import, trace, and overlay on real maps



🛠 3. How to Create This in AutoCAD – Step by Step

🔧 A. Setup

  • Open AutoCAD and start a new drawing
  • Set your drawing units to meters or appropriate scale
  • Turn on SNAP and GRID for clean alignments



📚 B. Create Layers for Each Land Use Type

Layer Name Color Suggestion Use For
Roads Grey Pathways, highways
Residential Yellow Housing zones
Commercial Red Shops, offices
Agricultural Green Farming zones
Open Space Blue Parks, lakes



✍️ C. Use Polyline Tool (PL)

  • Trace each area using PL (Polyline) command
  • Snap to grid corners for accuracy
  • Close each zone with C for closed polylines



🎨 D. Hatch Each Zone

  • Type HATCH
  • Choose appropriate solid or gradient fill
  • Use a different hatch style/color for each zone layer



🧱 E. Add Road Network

  • Use LINE or POLYLINE
  • Maintain width using Offset command (O) for typical road width: 3.5m, 7m, etc.



💡 4. Pro Tips for AutoCAD Land Use Projects

  • Use XREF to overlay real satellite or plot plans
  • Group zones with BLOCK or GROUP for future edits
  • Use MText to annotate later with zone names (optional)
  • Export to PDF or JPEG via PLOT for presentations



💾 5. Download This Drawing



[Click here to download Land Use DWG file]



🔗 6. Related Downloads

  • [Urban Housing Layout DWG]
  • [Masterplan with Zoning + Circulation]
  • [Township Plan with Community Spaces]



📊 7. Where to Use This in Real Life

  • Government planning submissions
  • B.Arch or MUP thesis projects
  • NGO or development sector site proposals
  • College studio exercises
